ABB2 – 31.8 – Ready for production
€1,000.00
The ultimate aero handlebars, ready for production.
Following our original Speeco ABB bars, these are made to give you as much support and comfort as possible in a more aerodynamic position than traditional handlebars.
We have designed multiple versions for customers over the last years, and we are making these available to be reproduced at a lower cost. Please see below for the specification of the versions.
Specs:
Material: AlSi10Mg
Weight: from 320g
Finish: Raw (to be painted for corrosion protection), painted in black/white, or custom painted.
Cable integration: At the sides of the stem (for Specialized SL8 stem for example) and through the stem (Deda superbox, FSA ACR)
Tested to 5 times the ISO 4210 norm, with additional side impact tests.
All Speeco products are made to order, expect a minimum 6-week delivery.
Description
| Version | Width – Top (mm | Width – Bottom (mm) | Height difference (mm) | Reach (mm) | Drop (mm) | UCI legal |
| UCI-Limit | 360 | 400 | 17 | 100 | 120 | yes |
| 1 | 350 | 385 | 25 | 110 | 125 | * |
| 2 | 350 | 370 | 20 | 70 | 120 | * |
| 3 | 340 | 390 | 20 | 117 | 127 | no |
| 4 | 315 | 390 | 15 | 120 | 155 | no |
| 5 | 300 | 370 | 20 | 120 | 130 | no |
| 6 | 350 | 400 | 10 | 105 | 130 | * |
*Only UCI legal with some shifters completely straight or turned out slightly.
Additional information
| Version | Version 1, Version 2, Version 3, Version 4, Version 5, Version 6, UCI limit |
|---|
